Marine BreakAway Couplings

Categories: , , Tags: ,
During fuel refueling, hose assemblies can be exposed to unintended loads caused by towing events, potentially causing hoses to rupture and leading to large leaks. DRIPLEX Marine BreakAway Couplings are designed to prevent and reduce leakage in such events.
Marine BreakAway Couplings are designed to break only with a pre-calculated force axially. Marine BreakAway Couplings are mounted only between two hoses. The coupling elements, being the weakest link of the loading or unloading system, are designed to break first. This ensures the safety of the hoses and the environment.
Viton® ve Kalrez®, are registered trademarks of DuPont Performance Elastomers.
Chemraz®, Is a registered trademark of Green-Tweed.



CALL NOW
INFORMATION FORM
DOWNLOAD CATALOG

Technical Specifications

Size Range
2 inches to 4 inches
Material
Stainless Steel and Aluminum. Other exotic materials are available upon request.
Seals
FKM (Viton®), NBR (Nitrile), EPDM, and FFKM (Chemraz®). Other sealing materials are available upon request.
End Fittings
BSP, NPT, ISO
Flange – ANSI, ASME, ISO, DIN
Working Pressure
Up to 25 bar
